Adalet HV4X6-242006 High Voltage Terminal Enclosures

Adalet

Product Code: HV4X6-242006
Brand: Adalet



GET OFFER: info@imtek.com.tr

Description for Adalet HV4X6-242006 High Voltage Terminal Enclosures

Standard Features•  31 standard sizes available in 1 x 1 or 2 x 2 connection options•  Stainless steel cover clamps and screws•  Continuous piano hinge with removable steel pin•  Watertight silicone gasket•  Set of three porcelain insulators (1 x 1) or mechanical connections (2 x 2)•  Adjustable mounting plate (1 x 1 and 2 x 2)•  Adjustable clamp rails (1 x 1 and 2 x 2)•  Padlock hasp and staple•  Internal rail mounting system•  Ground stud on box and coverDesign Options•  Gland plates (6” or greater) can be supplied pre-drilled or blank for field drilling•  Mounting panels•  Drilled entries and cut-outs•  UHWM-PE cable clamps (1 x 1 connection only)•  Breather / Drain•  Stopping plugs•  Terminal block assemblies•  Stainless steel mounting panels•  Cable glands and conduit fittings•  Internal earth bar Material•  Type 304 or 316L stainless steel•  Enclosure and cover constructed from 14 gauge (.075) stainless steel with #3/4 brush finish•  Gland plates constructed from 10 gauge (.1345) stainless steel with #3/4 brush finish•  Silicone gasket constructed from 1/4” Bisco silicone with acrylic PSA•  Gland plate gasket constructed from 1/8” Bisco silicone with acrylic PSA
