Adalet XIH Series Explosionproof Instrument Enclosure
Adalet
Product Code: XIH Series
Brand: Adalet
GET OFFER: info@imtek.com.tr
Description for Adalet XIH Series Explosionproof Instrument Enclosure
Standard Features• ½” or ¾” NPT conduit feed-through hubs, offset for maximum clearance and capacity• Four interior mounting bosses at 45° orientation accommodate blind tapped holes on a 2-1/2” bolt circle• 60 chamfer on window opening provides exhanced viewing angle• Internal and external ground screws and tamper resistant cover set screws for extra safety• Choice of solid covers or 2-5/8” diameter tempered glass window for local read out or display• Buna-Nitrile rubber gasket for NEMA Type 4X watertight applications• Corrosion resistant, “safety blue” polyester powder coating (other colors available)• Stainless steel hardwareDesign Options• ¼”-20 UNC holes in front boss for bracket mounting• Front boss modifications: ½” or ¾” NPT & various NPSM & metric entries available in place of standard ½” NPT (consult factory)• Mounting lugs with 5/16” holes (add suffix “L” to catalog number)• Powder or epoxy coatings to match company color scheme• Cast-on logos• Custom drilling & tapping modifications• Interior mounting bosses• Custom designs and sizesRecommended Products For Adalet
