FMS BKS309.R.EIP Web Guide Controller

Web Guide Controller

FMS Data sheet l BKS 309
BKS 309
l
l
Technical Data
Cycle time
1 ms
Drive of steering frame
Stepper motor, power amplifier 24 V integrated in motor housing
Dead band
0...2 mm, setting 0.01 mm steps
Reference position
±5 mm, setting in 0.1 mm steps
Control mode
Edge left, edge right, centre guiding, line guiding, chase & follow (option)
Interfaces
Ethernet via web browser Ethernet Explorer 7
Operation panel
3 buttons and 5-key wind-rose
Analogue Inputs
2 inputs 0...10 V (sensors), 1 potentiometer input 0...10 V (winderGLIDE)
Digital inputs
4 inputs at 24 VDC galvanically isolated
Relay outputs
2 contacts max. DC 220 V/2 A/60 W; AC 250 V/2 A/62.5 VA
Power supply
24 VDC (18...30 V); max. 80 W
Temperature range
0...55 °C
Housings
Rail mount, wall mount and panel mount
Protection class
IP 40 or IP 65 for wall mount version
BKS 309.R Rail Mount Housing l Dimensions in mm
Wiring is realised via cable terminals.
