Ayvaz V-TYPE Braided Loop Joint

Ayvaz

Product Code: V-TYPE
Brand: Ayvaz



GET OFFER: info@imtek.com.tr

Description for Ayvaz V-TYPE Braided Loop Joint

Ayvaz U-Flex and V-Flex assemblies provide highly flexible and reliable connection features for fire protection lines, seismic security areas, dilatation points and industrial applications. These assemblies are used to absorb the movements caused by the potential break downs and depressions especially where the seismic movements may cause hazardous results. Ayvaz U-Flex and V-Flex assemblies that are manufactured with FM certificate prevent the structural deformations such as cracks and break downs of rigid connections by the required flexibility they provide and offer easy, safe and reliable installation features for the users.DESIGNAyvaz U-Flex and V-Flex assemblies are consisted of the parallel corrugated metal hose with braiding and Carbon Steel connection and direction parts likewise turns and elbows at various angles. Flexible metal hose provides high movement capacity in all directions to the assemblies and the braiding increases the pressure resistance accordinglyStructureBellow Material: Stainless Steel AISI 316L / AISI 321Braiding Material: Stainless Steel AISI 304Connection Types: Flange, Welded End, GroovedFlange Material: Carbon Steel St. 37.2 , the material can be customized on requestElbow and Turn Material: Carbon Steel St. 37.2 , the material can be customized on requestOperating ConditionsOperating Temperature: -80°C/+600°COperating Pressure: 16 barNominal Diameters: DN15 (1/2”) - DN300 (12”)V-flex type connection absorbs all of the 3D Deflection and angular movements. This type connection protects plumbing system with its flexible constriction and doesn’t need wide area with its short overall length. Also it is produced according to FM certificate. For this reason, Ayvaz gimbal type expansion joint is the best choice for fire protection system.Materials:Hose: AISI 316L Stainless steelFittings: Carbon steel or Stainless steelConnection:Welded endFlangedDiameter Nominal:DN 12 (1/2”) - DN 200 (8")Application area:Dilatation points of fluid systems.
