Bartec Power Distribution Boards

Bartec

Product Code: Power Distribution Boards
Brand: Bartec



GET OFFER: info@imtek.com.tr

Description for Bartec Power Distribution Boards

for Zone 1/21 ApplicationsEconomic by reducing down times by fast access through windowsReliable because of the harsh design in stainless steel enclosureCompact through the combination of control and power distribution functionsFlexible concerning size and the used componentsCompletion of the BARTEC portfolioDescriptionBARTEC offers a complete solution for distribution of power for light and heat tracing projects. Based on customer requirements, the safety technology provider supplies a combination of standardized and customized enclosure sizes containing the BARTEC breakers for circuit protection/power distribution as well as the control station for controlling and monitoring the customer system.The components can be mounted on a galvanized metal or stainless steel frame with an option for sun and rain protection by a roof.Application:Power feed-in/distribution for lighting, heating, motors, connectorsArea of usage: Zone 1, 2, 21, 22Versions: ETO, up to 160 A, MCB, RCCB, RCBOTechnical DataData SheetsTechnical DataDimensionsType 1: 380 mm x 300 mm, one flapType 2: 760 mm x 300 mm, two flapsType 3: 760 mm x 600 mm, three/four flapsConnectionMCB (Main circuit breaker):1 pole up to 4 pole 0.5 A up to 40 A (15 values)optional with one signal or auxiliary contact availableRCCB (Residual current circuit breaker):1+N, 2 pole 25 A up to 63 A (3-values)/30, 100, 300, 500 mA residual currentRCBO (Residual current circuit breaker with overcurrent protection):
