EL6652 | EtherNet/IP master terminal
The EL6652 EtherNet/IP-Master Terminal has a switched 2-port Ethernet connection and can thus be operated in a line with
further Ethernet/IP nodes. The process data are configured by an EtherCAT master, allowing different process data and different
sizes. The EL6652 supports both multicast and unicast connections. Up to 16 simple EtherNet/IP-Slave devices can be connected
via one generic node. The EL6652 is optionally also available as a slave version.
Technical data EL6652 EL6652-0010
Technology EtherNet/IP master terminal EtherNet/IP slave terminal
Number of ports/channels 2 (switched)
Ethernet interface 100BASE-TX Ethernet with 2 x RJ45
Data length max. 1 kByte input and output data –
Cable length up to 100 m twisted pair
Hardware diagnosis status LEDs
Power supply via the E-bus
Electrical isolation 500 V (E-bus/Ethernet)
Protocol EtherNet/IP EtherNet/IP slave
Configuration via EtherCAT master
Current consumption E-bus typ. 400 mA
Special features multicast/unicast connection
Weight approx. 75 g
Operating/storage temperature 0…+55 °C/-25…+85 °C
Relative humidity 95 %, no condensation
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4
Protect. class/installation pos. IP 20/see documentation
Approvals/markings CE, UL
Ordering information
EL6652 EtherNet/IP master terminal, 2 x RJ45 switch
EL6652-0010 EtherNet/IP slave terminal
System
EtherNet/IP For further EtherNet/IP products please see the system overview.
