BECKHOFF KL1512 Up/down Counter,
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Others |
| Product Name | BECKHOFF KL1512 Up/down Counter, |
| Product Code | KL1512 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
BECKHOFF products, including BECKHOFF KL1512 Up/down Counter,, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine BECKHOFF parts at competitive prices. Even if BECKHOFF KL1512 Up/down Counter, is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The KL1512 Bus Terminal is a 2-channel up/down counter. It transmits the counter state to the higher-level automation device in an electrically isolated manner. The pulse of both counters is set via the inputs, the count direction can be changed to backwards via the register. The signal state of the inputs is indicated by light emitting diodes. The KL1512 is particularly suitable for simple counting tasks, e.g. in connection with flow meters.
| Technical data | KL1512 | KS1512 |
|---|---|
| Connection technology | 1 x up/down counter, 2 x up or down counter |
| Specification | EN 61131-2, type 1, “0”: < 5 V DC, “1”: > 15 V DC, typ. 5 mA |
| Number of counters | 1 or 2 |
| Nominal voltage | 24 V DC (-15 %/+20 %) |
| “0” signal voltage | -3…+5 V (EN 61131-2, type 1) |
| “1” signal voltage | 15…30 V (EN 61131-2, type 1) |
| Counting frequency | max. 1 kHz |
| Counter depth | 16 bit |
| Input current | typ. 5 mA (EN 61131-2, type 1) |
| Current consumption K-bus | typ. 50 mA |
| Current consumption power contacts | load only |
| Electrical isolation | 500 V (K-bus/field potential) |
| Bit width in the process image | input/output: 16 bit data, 8 bit control/status |
| Configuration | via the Bus Coupler or the controller |
| Special features | set counters |
| Weight | approx. 50 g |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals | CE, UL, Ex |
