BECKHOFF KL1808 HD Bus Terminal, 8-Channel Digital Input
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Terminal |
| Product Name | BECKHOFF KL1808 HD Bus Terminal, 8-Channel Digital Input |
| Product Code | KL1808 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
BECKHOFF products, including BECKHOFF KL1808 HD Bus Terminal, 8-Channel Digital Input, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine BECKHOFF parts at competitive prices. Even if BECKHOFF KL1808 HD Bus Terminal, 8-Channel Digital Input is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The KL1808 digital input terminal acquires the binary control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation device. The Bus Terminal contains eight channels, consisting of a signal input and 24 V DC. The signal states are displayed by LEDs. The power contacts are looped through.
For the KL1808 Bus Terminal, the reference ground for all inputs is the 0 V power contact. The wires can be connected without tools in the case of solid wires using a direct plug-in technique.
The HD Bus Terminals (High Density) with increased packing density feature 16 connection points in the housing of a 12 mm terminal block.
| Technical data | KL1808 |
|---|---|
| Connection technology | 2-wire |
| Specification | EN 61131-2, type 1/3 |
| Number of inputs | 8 |
| Nominal voltage | 24 V DC (-15 %/+20 %) |
| “0“ signal voltage | -3…+5 V (EN 61131-2, type 1/3) |
| “1“ signal voltage | 11…30 V (EN 61131-2, type 3) |
| Input filter | typ. 3.0 ms |
| Input current | typ. 3 mA (EN 61131-2, type 3) |
| Current consumption K-bus | typ. 15 mA |
| Current consumption power contacts | typ. 2 mA + load |
| Electrical isolation | 500 V (K-bus/field potential) |
| Bit width in the process image | 8 inputs |
| Configuration | no address or configuration setting |
| Conductor types | solid wire, stranded wire and ferrule |
| Conductor connection | solid wire conductors: direct plug-in technique; stranded wire conductors and ferrules: spring actuation by screwdriver |
| Rated cross-section | solid wire: 0.08…1.5 mm²; stranded wire: 0.25…1.5 mm²; ferrule: 0.14…0.75 mm² |
| Weight | approx. 60 g |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable (see documentation) |
| Approvals | CE, UL, Ex, GL |
