CD Automation REVEX 1PH Single-phase On Demand Power Controller

CD Automation

Product Code: REVEX 1PH
Brand: CD Automation



GET OFFER: info@imtek.com.tr

Description for CD Automation REVEX 1PH Single-phase On Demand Power Controller

REVEX 1PH is a fully configurable single phase power controller. If you don’t need features, delete them, so you’ll get an immediate cut on the cost of the unit.Load type: Normal Resistance, Infrared Short, Medium and Long, Transformer Primary, Cold resistance and SiC elementsInputs: 4:20mA, 0:10V, SSR and ModBus as std.Firing mode: Single cycle, Half cycle, Burst, Phase Angle, Delayed Triggering, different types of adjustable rampControl Mode: Voltage, Current and Power or V2 and I2 with additional Transfer to VxICommunication RS485 with Modbus® protocol std.Two Analog inputTwo digital inputsUSB: Port integrated for configuration in safety mode (No Load and Auxiliary Voltage needed) Unit Powered Through USBDual Current Limit: For peak and RMS valueWith the units already programmed you can simply switch On and GoOptionsAll options are shown below with the relevant model codeHB Alarm to diagnose partial or Total Load Failure and Thyristor Short CircuitPhases:1Type:Power controllerCurrent Range:30A - 280AMax Voltage:480V, 600VCommunication:ModbusApprovals:CE / UKCA / EACLoad:Resistive / Inductive / IRSW / MoSi2 / SiC
