Celem CSP 305A Conduction Cooled Capacitor
Celem
Product Code: CSP 305A
Brand: Celem
GET OFFER: info@imtek.com.tr
Description for Celem CSP 305A Conduction Cooled Capacitor
The CSP 305A and CSP 305B conduction-cooled capacitors provide up to 300 kVAr of power. These capacitors have similar electrical characteristic but differ in their physical dimensions and in the number of mounting holes. Please note that the newer CSP 405A and CSP305A/600 have the same physical dimensions as the CSP 305A but are rated for higher voltage and higher current and can carry up to 400 and 600kVAr respectively. Standard applications: Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc. Features: Polypropylene Conduction-cooled capacitor High Power Self-Healing capacitor Low ESR Low losses UL94-V0 available upon request. The CSP 305A capacitor complies with RoHS. Specifications TYPE CSP 305A Dimensions (LxWxH) mm 66 x 56 x 30.2 Weight kg 0.6 Capacitance (±10%) ?F 0.1 0.2 0.33 0.66 1 1.32 2.6 5 Sinusoidal Voltage Vrms 1000 700 600 500 400 Peak Voltage Vpeak 1410 990 850 710 570 Max. Current Arms 400 500 650 800 Max. Power kVAr 300 Freq Range @ Full Power kHz 477-700 239-424 295-402 148-201 133-224 100-170 73-86 60-68 Stray Inductance nH < 5Recommended Products For Celem
