Conductix Wampfler Series HL Motor Driven Reels Heavy Load

Conductix Wampfler

Product Code: Series HL
Brand: Conductix Wampfler



GET OFFER: info@imtek.com.tr

Description for Conductix Wampfler Series HL Motor Driven Reels Heavy Load

Modular assembly system - the cable reel can be upgraded after installation by adding drive units.Magnetic Coupler Drive (MAG Drive) or Variable Frequency Drive (SMART Drive)5 year or 15,000 hour operation before any maintenance is required - gearboxes are grease-lubricated from the factory.Optimal corrosion protection to handle aggressive environments - flanges and reel drum are manufactured from hot dip galvanized steel or stainless steel.Typical applications:Ship-to-shore (STS) cranesRail mounted gantry (RMG) cranesShip unloadersStackers / reclaimersShipbuilding cranesTravel speed:- AC motor with magnetic coupler (MAG drive): up to 100 m/min- Variable frequency controlled (SMART Drive): up to 180 m/minWinding length: 700 m maxOD of spool:- Monospiral spool: 1,100 mm - 8,000 mm- 3-2-3 spool: 1,100 mm - 8,000 mmGearbox:- Type BNA: 1,100 Nm - 19,000 Nm- Type X07: 1,100 Nm - 11,000 NmSlip ring assembly:- Power low voltage max: 690 V - 1,600 A- Power high voltage max: 24,000 V - 500 A- Control max: 500 V - 25 A- Data: fiber optic, mATemperature range: -40 °C - +60 °C
