Conductix Wampfler Series LR Motor Driven Reels - Long Range

Conductix Wampfler

Product Code: Series LR
Brand: Conductix Wampfler



GET OFFER: info@imtek.com.tr

Description for Conductix Wampfler Series LR Motor Driven Reels - Long Range

Extra long travel distance - single or multi-layer drum type spool.Skeleton-type drum for optimal cable cooling and reduced inertia.Modular platform construction allows multiple arrangements and best fit with machine structure.Rugged construction for harsh environments.Typical applications:Stackers / reclaimersBucket wheel excavatorsTripper carsMobile conveyorsScrapersStack rakesTravel speed: up to 60 m/minWinding length: 2,000 m maxOD of drum: up to 3.3 mGearbox:- BNA: 1,000 Nm - 18,000 Nm- SMART Drive: 1,000 Nm - 8,500 NmSlip ring assembly:- Power low voltage max: 690 V - 1,600 A- Power high voltage max: 36,000 V - 500 A- Control max: 500 V - 25 A- Data: fiber optic, mATemperature range: -40 °C - +60 °C
