Dynisco IDA372-20-D08-D30/10 Pressure Transmitters

Dynisco

Product Code: IDA372-20-D08-D30/10 Pressure Transmitters
Brand: Dynisco



GET OFFER: info@imtek.com.tr

Description for Dynisco IDA372-20-D08-D30/10 Pressure Transmitters

The PTs of series IDA are industry standard. The most important advantages are:Manufactured under ISO 9001  Thermal stabilityInsensitivity to pressure peaksInsensitivity to electromagnetic radiation (EMC) Fully welded housingPotted electronicsMaximum pressure 1000 barThrough a diaphragm, the PT furnishes an electrical signal that is proportional to the pressure of the medium. The pressure applied by the medium is forwarded to the measuring diaphragm. The deflection of the measuring diaphragm changes the resistance of the strain gauge bonded to the measuring diaphragm. The strain gauge is a Wheatstone bridge. Dependent on the PT model, an electric signal proportional to the pressure is generated via the supply voltage or the amplifier.Pressure transducer IP54 (without connector) Standard female cable connector DIN IP40 Female cable connector option D06 IP65 Cable connection option D05 IP67IDA33x Internal thread ISO228/1-G¼ IDA35x Screw-in trunnion with external thread DIN 3852-A G¼A IDA37x Screw-in trunnion with external thread M18 x 1.5 flush diaphragm
