Dynisco PT4604-3M-12-A Pressure Sensors

Dynisco

Product Code: PT4604-3M-12-A Pressure Sensors
Brand: Dynisco



GET OFFER: info@imtek.com.tr

Description for Dynisco PT4604-3M-12-A Pressure Sensors

·         Adjustable zero and span, via side-mounted pots·         Accuracy better than ±0.5%·         DyMax® coated stainless steel wetted parts·         4-20 mA output·         0-500 to 0-30,000 psi·         Internal 80% shunt calibration·         3rd-party agency analysis (exida™) and self-certified based on FMEDA analysis and internal audit·         Output signal meets Performance Level ‘c’ as defined bythe Machinery Directive (Category 1)·         Meets the following compliance directives, when properlyinstalled and used:– SIL2–Machinery Directive EN ISO 13849-1   The PT46X4 Series pressure sensor is a ±0.5% sensor ideal for general melt pressure measurements requiring simple installation, repeatability and reliability. The PT46x4 sensor provides the industry standard 4-20 mA amplified signal designed to work with DCS and PLCs. The PT46X4 comes equipped with adjustable zero and span side-mounted potentiometers. PT46X4 Series mA sensors can be rezeroed in two ways: locally via the zero potentiometer, or remotely via shorting two pins together (contact closure). Optional thermocouple or RTD configurations are available to provide melt temperature. The PT46X4 features a 1/2-20 UNF thread for simple and easy installation in standard transducer mounting holes. The 4-20 mA output signal is rated PL‘c’ as described in the Machinery Directive EN ISO 13849-1. The PT46X4 Series mA sensors are self-certified based on the evaluation reports of the respected third-party agency, exida™. The PT46X4 Series mA sensors have undergone extensive FMEDA analysis (Failure Mode Effects and Diagnostic Analysis). The FMEDA reports show that these sensors have been evaluated for random failure requirements and meet Performance Level ‘c’ (PL‘c’) as well as SIL2 (Safety Integrity Level 2). The information in the FMEDA report can be used by the customer’s system designer as part of the overall qualification of the device in the system for PL‘c’ or SIL compliance. The PT46X4 Series can be equipped with a safety relay, separate from the signal output. Called Guardian, this optional relay signal has an application specific pressure threshold setting that will place a machine in a safe mode as described in the Machinery Directive EN ISO 13849-1. The PT46x4 sensor provides the industry standard 4-20 mA amplified signal designed to work with DCS and PLCs. The PT46X4 comes equipped with adjustable zero and span side-mounted potentiometers. PT46X4 Series mA sensors can be rezeroed in two ways: locally via the zero potentiometer, or remotely via shorting two pins together (contact closure). Optional thermocouple or RTD configurations are available to provide melt temperature. Features a 1/2-20 UNF thread for simple and easy installation in standard transducer mounting holes. The PT46X4 Series includes models PT4604, PT4624, PT4634, TPT4604, TPT4624, and TPT4634.
