Eaton DTEF 1652 Duplex Filter

Eaton

Product Code: DTEF 1652
Brand: Eaton



GET OFFER: info@imtek.com.tr

Description for Eaton DTEF 1652 Duplex Filter

Eaton´s return line filter of the DTEF seires have a working pressure up to 145 psi (10 bar). Pressure peaks will be absorbed by a sufficient margin of safety.The DTEF-filters are directly mounted to the reservoir and connected to the return-line. When changing the filter element, a detachable connection between the filter head and the filter bowl prevents dirty oil from flowing into the tank. FILTER TYPETank mountedMAX. OPERATING PRESSURE145 psi (10 bar)OPERATING TEMPERATURE14-212 °F (-10-100 °C) Core features Easy to service High intrinsic stability Excellent filtration capability High dirt-retaining capacity Long service life  SPECIFICATIONS operating temperature: +14 °F to +212 °F operating medium: mineral oil, other media on request max. operating pressure: 145 PSI opening pressure by-pass valve: 29 PSI / 51 PSI process connection: thread connection housing material standard: filter head AL, screw plug / filter bowl glass fiber reinforced polyamide housing material IS10, category 2 and 3: filter head AL, screw plug / filter bowl glass fiber reinforced polyamide sealing material: Nitrile (NBR) or Viton (FPM), other materials on request installation position: vertical volume tank: 2x .08 Gal.
