EKF CB2-PIPE 3U, CompactPCI 5-Port USB 2.0 Host Controller

EKF

Product Code: EKF CB2-PIPE 3U, CompactPCI 5-Port USB 2.0 Host Controller
Artikelnummer: CB2-PIPE
Brand: EKF



GET OFFER: info@imtek.com.tr

Description for EKF CB2-PIPE 3U, CompactPCI 5-Port USB 2.0 Host Controller

3U Eurocard (100x160mm2)Front panel width 4HPPeripheral Card 32bit, 33MHz (133MBps), 3.3V or 5V interfaceReady for usage within PXI® systemsRoot hub with 5 downstream facing ports, all ports over-current protected, data transfer rate up to 480Mbps, conforming to USB2.0, OHCI Rev. 1.0a, EHCI Rev. 1.0Proven PCI to USB 2.0 controller NEC (Renesas) uPD720101USB port 1-4 wired to front panel type A connectorsUSB port 1-4 optionally wired to J2 for rear I/O usage (front panel connectors USB1-4 removed), stuffing option - please take into consideration before orderingUSB port 5 wired to the on-board type A connector+5V ±5% 0.1A max. (w/o current required by USB devices via VBUS)+3.3V +0.17V/-0.1V 0.4A max. (w/o on-board Flash disk drive option)Vio 3.3V/5V 0.1A max.Operating temperature: 0°C to +70°C • industrial temperature range on requestStorage temperature: -40°C to +85°C, max. gradient 5°C/minHumidity 5% ... 95% RH non condensingAltitude -300m ... +3000mShock 15g 0.33ms, 6g 6msVibration 1g 5-2000HzMTBF 0.333 * 106hCoating, sealing, underfilling on requestRoHS compliant 2002/95/ECEC Regulations EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1)
