Enerpac CLRG5010 Hydraulic Cylinder

Enerpac

Product Code: CLRG5010
Brand: Enerpac



GET OFFER: info@imtek.com.tr

Description for Enerpac CLRG5010 Hydraulic Cylinder

Double-acting, for positive retraction. Integral stop ring provides piston blow-out protection. Safety valve in retract side of cylinder helps to prevent damage in case of accidental over-pressurization. Plunger wiper reduces contamination, extending cylinder life. CR-400 coupler and dust cap included on all models. Baked enamel finish and plated pistons provide superior corrosion resistance.Specifications(Kg): 31Stroke (mm): 250Cylinder Bore Diameter E (mm): 99Cylinder Capacity ton (kN): 50 (539)Plunger Diameter F (mm): 70Base to Advance Port H (mm): 52Saddle Protr. from Plgr. K (mm): 1Outside Dia. D (mm): 130Standard Saddle Dia. J (mm): 50Depth of Plunger Hole L (mm): 19Extend. Height B (mm): 612Cylinder Effective Area (cm2) Push: 77,0Cylinder Effective Area (cm2) Pull: 38,5Oil Capacity (cm3) Push: 1924Oil Capacity (cm3) Pull: 962Top to Retract Port I (mm): 33Collaps. Height A (mm): 362
