Maximum Operating Pressure10,000 psi (690 bar)Maximum Operating Pressure 1st Stage197 psi (13,8 bar)Maximum Operating Pressure 2nd Stage10,000 psi (700 bar)Reservoir Capacity35.4 in3 (580 cm3)Usable Oil Capacity35.4 in3 (580 cm3)Nominal Oil Capacity33.6 in3 (550 cm3)Maximum Flow at Rated Pressure0.047 in3/stroke (0,77 cm3/stroke)Oil Volume per Stroke 1st Stage0.221 in3 (3.62 cm3)Oil Volume per Stroke 2nd Stage0.047 in3 (0.77 cm3)Maximum Handle Effort55.12 lbs (25 kg)Piston Stroke0.71 in (18 mm)Power SourceManualPackaging Dimensions9.84 x 7.09 x 27.56 in (250 x 180 x 700 mm)Overall Length26.34 in (669 mm)Handle Length19.29 in (490 mm)Weight17.9 lbs (8,1 kg)
Get the best price and fastest delivery for Enerpac HP550DMINEX Atex Certified Twin Port Sealed Hand Pump from Enerpac. Imtek Engineering offers worldwide industrial equipment supply with expert support.
