Fairchild M2500A High Flow Reversing Relay

Fairchild

Product Code: M2500A
Brand: Fairchild



GET OFFER: info@imtek.com.tr

Description for Fairchild M2500A High Flow Reversing Relay

FeaturesControl sensitivity of 1" water column.Flow capacity of 150 SCFM (255 m3/HR).Soft Supply and Exhaust Valve seats.Balanced Supply Valve.Aspirator Tube design.Separate Control Chamber.BenefitsAllows use in precision applicationsProvide fast and responsive system operation.Minimizes air consumption.Minimizes the effect of supply pressure variationCompensates downstream pressure droop under flow conditionsIsolates the diaphragm from the main flow to eliminate hunting and buzzingThe Model 2500A Bias Reversing Relay provides an outlet pressure that decreases in direct proportion to increases in input signal. The input signal that acts on the Diaphragm Assembly opposes the Range Spring force and closes the Supply Valve to decrease output pressure, according to the formula (Po = K - Ps); where Po is output pressure, K is the spring constant, set by the screw, and Ps is signal pressure. The M2500A pneumatic relay delivers this performance at a flow capacity of 150 SCFM (255 m3/HR), to provide fast response and tight control over your application.
