Felm FX 355XA-8 Motor

Felm

Product Code: FX 355XA-8
Brand: Felm



GET OFFER: info@imtek.com.tr

Description for Felm FX 355XA-8 Motor

Compact Series Motors Technical details: Efficiency level: Premium IE3 Motors < 220 kW - > 1000 kW High efficiency level Number of Poles: 2 up to 12 Frequency: 50 Hz. (Optional: 60 Hz.) Voltage: 400 V. (Optional: other rated voltages) Frames: 315 up to 560 Cast iron frame Cooling system: IC411 (Options: IC416 Inverter use rated 1:10) Die cast Aluminum Rotor Color: RAL 5010 (Blue) (Options: others type of colour) Shaft sealing: O´Ring VPI Insulation System Insulation class F (class B temperature rise) (Options: Class H) Ramdom winding from 315X/355X/400X/450X Formed winding for 500X and 560X frame Degree of protection: IP55 (Options: IP56 - IP65) Mounting: B3 (Options: B35 - V1) Painting plan: (Options: Marine - Chemical - Munsell) Internal epoxy coating (tropicalized) Sintered drain plug Terminal block on top Shaft Material: C45 Double grounding (1 inside terminal box + 2 on the frame) Grease Caltex SRI-2 or SKF LGHP2 (Different types recommended by Felm) Regreasing system for frames 315 up to 560 Options: Space Heaters connected in separate auxiliary terminal box Predisposition and All type of Encoder Special shaft materials DC or AC Brake
