FIP Italy DKOM Series DN 15÷65 DIALOCK® 2-way Diaphragm Valve

FIP Italy

Product Code: DKOM Series DN 15÷65
Brand: FIP Italy



GET OFFER: info@imtek.com.tr

Description for FIP Italy DKOM Series DN 15÷65 DIALOCK® 2-way Diaphragm Valve

DIALOCK® diaphragm valve with flanged monolithic body, drilled PN10/16. Face to face according to EN 558-1DIALOCK® 2-WAY DIAPHRAGM VALVE• Connection system for solvent weld, threaded and flanged joints• Optimised fluid dynamic design: maximum output flow rate thanks to theoptimised efficiency of the fluid dynamics that characterise the new internalgeometry of the body• Internal components in metal, totally isolated from the fluid and externalenvironment• Modularity of the range: only 2 handwheel and 4 diaphragm and bonnetsizes for 7 different valve sizes• Non-rising handwheel that stays at the same height during rotation,equipped with a graduated optical indicator protected by a transparentPVC cap with seal O-Ring• Bonnet fastening screws in stainless steel protected against the externalenvironment by PE plugs. Absence of metal parts exposed to the externalenvironment to prevent any risk of corrosion• New flanged bodies: the new bodies, characterised by a monolithicflanged structure, are available in PVC-U, PVC-C, PP-H and PVDF. Thisdesign, free from body and flange joints, greatly reduces mechanical stressand increases system performance.• CDSA (Circular Diaphragm Sealing Angle) system that, thanks to theuniform distribution of shutter pressure on the diaphragm seal, offers thefollowing advantages:??reduction in the tightening torque of the screws fixing the actuator tothe valve body??reduced mechanical stress on all valve components (actuator, body anddiaphragm)??easy to clean valve interior??low risk of the accumulation of deposits, contamination or damage tothe diaphragm due to crystallisation??operating torque reduction EPDM code FKM code PTFE code DKOM020E DKOM020F DKOM020P DKOM025E DKOM025F DKOM025P DKOM032E DKOM032F DKOM032P DKOM040E DKOM040F DKOM040P DKOM050E DKOM050F DKOM050P DKOM063E DKOM063F DKOM063P DKOM075E DKOM075F DKOM075P
