FIP Italy VKDFC Series DN 65÷10 DUAL BLOCK® 2-way Ball Valve

FIP Italy

Product Code: VKDFC Series DN 65÷10
Brand: FIP Italy



GET OFFER: info@imtek.com.tr

Description for FIP Italy VKDFC Series DN 65÷10 DUAL BLOCK® 2-way Ball Valve

DUAL BLOCK® 2-way ball valve with BSP threaded female endsDUAL BLOCK® 2-WAY BALL VALVE• Connection system for solvent weld, threaded and flanged joints• Patented SEAT STOP® ball carrier system that lets you micro-adjust sealsand minimise axial force effects• Easy radial disassembly allowing quick replacement of O-rings and ballseats without any need for tools• PN16 True Union valve body made for rigid PVC-C injection mouldingequipped with built-in bores for actuation. ISO 9393 compliant test requisites• Option of disassembling downstream pipes with the valve in the closedposition• Full bore ball with high surface finish• Carrier integrated in the body for valve anchoring]• Possibility of installing a manual reducer or pneumatic and/or electric actuatorsby applying an ISO standard drilling pattern PP-GR flange• STAINLESS steel co-moulded stem, with square section as per ISO 5211• Valve material compatibility (PVC-C) and elastomer seal elements (EPDMor FKM), with water, drinking water and other food substances as percurrent regulations• Possibility to have handle with integrated LSQT limit micro switch, even asa retrofit in existing installations EPDM code FKM code VKDFC212E VKDFC212F VKDFC300E VKDFC300F VKDFC400E VKDFC400F
