FIP Italy VKROV Series DN 10÷50 DUAL BLOCK® Regulating Ball Valve

FIP Italy

Product Code: VKROV Series DN 10÷50
Brand: FIP Italy



GET OFFER: info@imtek.com.tr

Description for FIP Italy VKROV Series DN 10÷50 DUAL BLOCK® Regulating Ball Valve

DUAL BLOCK® regulating ball valve with EN/ISO/DIN fixed flange, drilled PN10/16. Face to face according to EN 558-1DUAL BLOCK® REGULATING BALL VALVE• Connection system for solvent weld, threaded and flanged joints• Patented SEAT STOP® ball carrier system that lets you micro-adjust sealsand minimise the axial force effect• Easy radial dismounting allowing quick replacement of O-rings and ballseats without any need for tools• PN16 True Union valve body made for rigid PVC-U injection mouldingequipped with built-in bores for actuation. ISO 9393 compliant test requisites• Option of dismounting downstream pipes with the valve in the closedposition• High surface finish stem with double O-Ring and double connection key toball• Integrated bracket for valve anchoring• Ball seat carrier can be adjusted using the Easytorque adjustment kit• Actuation option: version with electric modulating actuator with 4-20 mA/ 0-10 V inlet and 4-20 mA / 0-10 V outlet to monitor the position• Valve suitable for carrying fluids that are clean and free of suspendedparticles EPDM code FKM code VKROV020E VKROV020F VKROV025E VKROV025F VKROV032E VKROV032F VKROV040E VKROV040F VKROV050E VKROV050F VKROV063E VKROV063F
