Product Description
FMS products, including FMS BKS020 Steering Frame, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine FMS parts at competitive prices. Even if FMS BKS020 Steering Frame is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
FMS-webMASTER 020
Dimensions in mm
FMS-webMASTER 020
Dimensions in mm
l
The Point is Technology
FMS-webMASTER Type
A
B
C
K
D
E
F
G
H
AL 1)
BKS 020.3.0250.0280.050
50
250
280
197
45
226
9
190
300
± 15
BKS 020.3.0300.0290.050
50
300
290
197
45
226
19
190
350
± 25
BKS 020.3.0400.0320.050
50
400
320
197
45
251
24
215
450
± 25
BKS 020.3.0400.0320.075
75
400
320
222
45
251
24
215
450
± 25
BKS 020.3.0500.0405.075
75
500
405
222
45
336
24
300
550
± 25
BKS 020.3.0600.0455.075
75
600
455
222
45
386
24
350
650
± 25
1) AL = Correction
Other sizes on request, maximum roller lenght = 600 mm
l
Technical data
Upper part bearing
3-point (B 500: 5-point)
Adjusting speed
> 35 mm / s
Order code (example):
FMS-webMASTER 020 BKS020.3.500.405.075.D
Drive
With ball screw and stepper motor, 24 V / max. 2.5 A
Series •
Temperature range
0...60 °C
Roller length •
Protection class
IP 30
Frame length • Roller diameter • Roller surface •
World Headquarters:
FMS Force Measuring Systems AG Aspstrasse 6 8154 Oberglatt (Switzerland)
Phone + 41 44 852 80 80 Fax + 41 44 850 60 06 [email protected]
www.fms-technology.com
FMS USA, Inc.
2155 Stonington Avenue Suite 119 Hoffman Estates, IL 60169 Phone + 1 847 519 4400
Fax + 1 847 519 4401
[email protected]
FMS UK Highfield, Atch Lench Road Church Lench Evesham WR 11 4UG Phone + 44 1386 871023
Fax + 44 1386 871021
[email protected]
FMS Italy Via Baranzate 67 20026 Novate Milanese Phone + 39 02 39487035
Fax + 39 02 39487035
[email protected]
All data have been prepared and checked carefully. However, we cannot assume
liability for any errors or incompletness. Subject to modifications serving progress.
11.12.04.002/8.e
FMS-webMASTER 020
