Gestra UNA14

Gestra

Product Code: UNA14
Brand: Gestra



GET OFFER: info@imtek.com.tr

Description for Gestra UNA14

Description UNA 14, UNA 16, UNA 16A are ball float steam traps with rolling ball valve. The steam traps can be used for all operating conditions, as they are unaffected by back pressure. They consist of a body with bolted cover and a control unit. The control unit is freely accessible after removing the cover. It can be completely replaced without having to remove the valve body from the line. A conversion of “h” design to “v” design or vice versa is possible without any problem by repositioning body and control unit. The direction of flow is indicated by an arrow, the position of installation by the word “Top” on the name plate. ? suitable for large condensate flowrates ? “h”-design for horizontal lines ? “v”-design for vertical lines (To convert “h” to “v” design or vice versa turn cover and control unit respectively) UNA 14, UNA 16, UNA 16A The following three different types of control units are available: Control unit “SIMPLEX”: level-dependent float control particularly suitable for cold condensate. Control unit “SIMPLEX R”: level-dependent float control with internal vent pipe for continuous air-venting. Control unit “DUPLEX”: float control with temperature-dependent automatic air-venting of saturated steam systems.
