General information:
Product name: MTR 15-16/16
A-W-A-HUUV
Product No: On request
EAN number: On request
Technical:
Pump speed on which pump data are
based:
2923 rpm
Rated flow: 283 l/min
Rated head: 181.1 m
Chambers: 16
Impellers: 16
Number of reduced-diameter impellers: 0
Drainage back to tank (Yes/No): N
Pump orientation: Vertical
Primary shaft seal: HUUV
Code for shaft seal: HUUV
Approvals: CE,EAC,UKCA,Morocco
Approvals for motor: CE,EAC,UKCA,SEPRO,Mor
occo
Energy approvals for motor: CE,CC,Singapore,Aust./N.Z
.
Curve tolerance: ISO9906:2012 3B
Pump version: A
Model: A
Materials:
Type key, code for materials: A
Pump head: Cast iron
EN 1561 EN-GJL-200
ASTM A48-25B
Impeller: Stainless steel
EN 1.4301
AISI 304
Material code: A
Get the best price and fastest delivery for Grundfos 98383020 MTR15-16/16 A-W-A-HUUV 3x400/690 50Hz Pump from Grundfos. Imtek Engineering offers worldwide industrial equipment supply with expert support.
