HEIDENHAIN LB 382 Multi Section Sealed Linear Encoder

HEIDENHAIN

Product Code: LB 382 Multi Section
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN LB 382 Multi Section Sealed Linear Encoder

Specifications LB 382 from ML 3240 mm Measuring standard Coefficient of linear expansion Rustproof steel scale tape with AURODUR graduation, grating period 40 µm Same as machine main casting Accuracy grade ±5 µm Measuring length ML* Kit with single-section AURODUR steel tape and housing sections for measuring lengths from 3240 mm to 30 040 mm in 200 mm steps (up to 72 040 mm upon request) Housing section lengths: 1000 mm, 1200 mm, 1400 mm, 1600 mm, 1800 mm, 2000 mm Reference mark* LB 382 LB 382 C Selectable by selector plate every 50 mm Distance-coded Interface ? 1 VPP Signal period 40 µm Diagnostics interface Analog Cutoff frequency –3 dB ? 250 kHz Electrical connection Separate adapter cable (1 m/3 m/6 m/9 m) connectible to mounting block Cable length1) ? 150 m Voltage supply without load DC 5 V ±0.25 V/< 150 mA Traversing speed ? 120 m/min (max. acceleration in measuring direction ? 60 m/s2) Required moving force ? 15 N Vibration 55 Hz to 2000 Hz Shock 11 ms ? 300 m/s2 (EN 60 068-2-6) ? 300 m/s2 (EN 60 068-2-27) Operating temperature 0 °C to 50 °C Protection EN 60 529 IP53 when mounted according to the instructions and mounting information IP64 if compressed air is connected via DA 400 Mass 1.3 kg + 3.6 kg/m measuring length * Please select when ordering 1) With HEIDENHAIN cable
