HEIDENHAIN LIDA 407 Exposed Linear Encoder

HEIDENHAIN

Product Code: LIDA 407
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN LIDA 407 Exposed Linear Encoder

Linear scaleLIDA 407Measuring standardCoefficient of linear expansionSteel scale tape with METALLUR scale grating; grating period 20 µm?therm  10 · 10–6 K–1Accuracy grade*±3 µm (up to ML 1040); ±5 µm (from ML 1240); ±15 µm1)Baseline error? ±0.750 µm/50 mm (typical)Measuring length ML* in mm 240 440 640 840 1040 1240 1440 1640 1840 2040 2240 2440 2640 28403040 3240 3440 3640 3840 4040 4240 4440 4640 4840 5040 5240 5440 56405840 6040Reference marksOne at midpoint of measuring lengthMass25 g + 0.1 g/mm measuring lengthScanning headLIDA 48LIDA 47Interface  1 VPP? TTLIntegrated interpolation*Signal period–20 µm5-fold4 µm10-fold2 µm50-fold0.4 µm100-fold0.2 µmCutoff frequency –3 dB? 400 kHz–Scanning frequency*–? 400 kHz? 200 kHz? 100 kHz? 50 kHz? 200 kHz? 100 kHz? 50 kHz? 25 kHz? 50 kHz? 25 kHz? 12.5 kHz? 25 kHz? 12.5 kHz? 6.25 kHzEdge separation a2)–? 0.100 µs? 0.220 µs? 0.465 µs? 0.950 µs? 0.100 µs? 0.220 µs? 0.465 µs? 0.950 µs? 0.080 µs? 0.175 µs? 0.370 µs? 0.080 µs? 0.175 µs? 0.370 µsTraversing speed2)? 600 m/min? 480 m/min? 240 m/min? 120 m/min? 60 m/min? 240 m/min? 120 m/min? 60 m/min? 30 m/min? 60 m/min? 30 m/min? 15 m/min? 30 m/min? 15 m/min? 7.5 m/minInterpolation error±45 nm–Limit switchesL1/L2 with two different magnets; output signals: TTL (without line driver)Electrical connectionCable, 0.5 m, 1 m or 3 m with D-sub connector (male) 15-pinCable lengthSee interface description, however limit: ? 20 m (with HEIDENHAIN cable)Voltage supplyDC 5 V ±0.5 VCurrent consumption< 130 mA< 150 mA (without load)Vibration 55 Hz to 2000 HzShock 6 ms? 500 m/s2 (EN 60 068-2-6)? 1000 m/s2 (EN 60 068-2-27)Operating temperature–10 °C to 70 °CMass Scanning head Connecting cable Connector20 g (without cable)22 g/m32 g* Please select when ordering1) ±5 µm after linear length-error compensation in the evaluation electronics2) At a corresponding cutoff or scanning frequency
