HEIDENHAIN ROC 2390M 1110412-01 Angle Encoder With Integral Bearing

HEIDENHAIN

Product Code: ROC 2390M
Artikelnummer: 1110412-01
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN ROC 2390M 1110412-01 Angle Encoder With Integral Bearing

Measuring standard  DIADUR graduation on glass disk   Measuring method  absolute (singleturn)   System accuracy  ± 5"   Maximum position error per signal period  ± 0.4"   Mechanical device version  Solid shaft for separate shaft coupling   Shaft type  Solid shaft   Shaft diameter  10 mm   Flange version  Rectangular flange with 80 mm centering collar, aluminum   Interface  Mitsubishi High Speed Serial Interface   Ordering designation  Mit03-4   Positions per revolution  67108864 (26 bit)   Electrical permissible speed  ? 3000 min?¹   Clock frequency  Specific to interfaces   Calculation time tcal  no specified value   Incremental signals  without   Output signals per revolution  16384   Cutoff frequency (-3 dB)  no specified value   Permissible cable length (with HEIDENHAIN cable)  ? 30 m   Power supply  DC 3.6 V ... 14 V   Typical current consumption without load  ? 140 mA at 5 V   Power consumption  ? 1.1 W at 3.6 V ? 1.3 W at 14 V   Connecting direction  Cable outlet for axial and radial use   Cable type  PUR Ø 6.0 mm   Cable length  1 m   Electrical connection  Coupling M12, male, 8-pin   Mechanical permissible speed  ? 3000 min?¹   Starting torque at 20 °C  0.02 Nm   Moment of inertia of the rotor (shaft)  0.000050 kgm²   Shaft load  axial 30 N radial 30 N at shaft end   Vibration 55 Hz to 2000 Hz (EN 60068-2-6)  ? 200 m/s²   Shock 6 ms (EN 60068-2-27)  ? 1000 m/s²   Maximum operating temperature  ? +60 °C   Minimum operating temperature  ? -20 °C   Degree of protection  IP 64 (EN 60529)   Mass  1.0 kg
