HEIDENHAIN RON 785C 355880-30 Angle Encoder With Integral Bearing

HEIDENHAIN

Product Code: RON 785C
Artikelnummer: 355880-30
Brand: HEIDENHAIN



GET OFFER: info@imtek.com.tr

Description for HEIDENHAIN RON 785C 355880-30 Angle Encoder With Integral Bearing

Measuring standard  DIADUR graduation on glass disk   Measuring method  incremental   System accuracy  ± 2"   Maximum position error per signal period  ± 0.7"   Mechanical device version  Hollow shaft with integrated stator coupling   Shaft type  Hollow through shaft   Shaft diameter  50 mm   Flange version  Flange with 170 mm outside diameter and 140 mm centering collar, drainage channels, aluminum   Interface  1 Vpp   Cutoff frequency (-3 dB)  ? 180 kHz   Reference mark  distance-coded   Nominal increment of reference marks  1000C   Line count  18000   Incremental signals  1 Vpp   Power supply  DC 5 V (±10 %)   Total current without load  ? 150 mA   Connecting direction  Cable outlet for axial and radial use   Cable type  PUR Ø 6.0 mm   Cable length  1 m   Electrical connection  Coupling M23, male, 12-pin   Permissible cable length (with HEIDENHAIN cable)  ? 150 m   Mechanical permissible speed  ? 1000 min?¹   Starting torque at 20 °C  ? 0.5 Nm   Moment of inertia of the rotor (shaft)  0.0010500 kgm²   Permissible axial motion of measured shaft  ± 0.1 mm   Natural frequency  ? 1000 Hz   Vibration 55 Hz to 2000 Hz (EN 60068-2-6)  ? 100 m/s²   Shock 6 ms (EN 60068-2-27)  ? 1000 m/s²   Maximum operating temperature  ? +50 °C   Minimum operating temperature  ? 0 °C   Degree of protection  IP 64 (EN 60529)   Mass  2.5 kg
