HFB 722507 WA Flanged Bearing House

HFB

Product Code: 722507 WA
Brand: HFB



GET OFFER: info@imtek.com.tr

Description for HFB 722507 WA Flanged Bearing House

These flanged bearing housings are designed to use self aligning ball bearings series 12 K and 22 K or spherical roller bearingsseries 222 K. Fixing of the bearings on the shaft is by means of an adapter sleeve.HFB supplies these housings for through shaft (Arrangement B) and as an end bearing housing with end cover (ArrangementA).Flanged bearing housings series 7225.. are sealed with felt strip and designed for grease lubrication. A R1/8" grease hole isincorporated in the housing for eventual later greasing. For shaft diameters 20 - 60 the housing is supplied in a triangularform with 3 mounting bolts, for the shaft range 65 - 100 in square form with 4 mounting holes.The bearing seat in the housing is designed with a bore tolerance H7 and for a floating bearing. Locating bearingarrangements are obtained by fitting the matching fixing rings between the housing shoulder and bearing outer race.7225(00) Flanged bearing Housings are manufactured from grey cast. On request housings manufactured from ductile iron can also be delivered.
