Hirschmann MACH104-20TX-FR Switch

Hirschmann

Product Code: MACH104-20TX-FR Switch
Brand: Hirschmann



GET OFFER: info@imtek.com.tr

Description for Hirschmann MACH104-20TX-FR Switch

Description:24 ports Gigabit Ethernet Industrial Workgroup Switch (20 x GE TX ports, 4 x GE SFP combo Ports), managed, Software Layer 2 Professional, Store-and-Forward-Switching, IPv6 Ready, fanless designPart Number:942 003-101Port type and quantity:24 ports in total; 20x (10/100/1000 BASE-TX, RJ45) and 4 Gigabit Combo Ports (10/100/1000 BASE-TX, RJ45 or 100/1000 BASE-FX, SFP)More InterfacesPower supply/signaling contact:1 x plug-in terminal block, 2-pin, output manual or automatic switchable (max. 1 A, 24 V DC bzw. 24 V AC)V.24 interface:1 x RJ11 socket, serial interface for device configurationUSB interface:1 x USB to connect auto-configuration adapter ACA21-USBNetwork size - length of cableTwisted pair (TP):0-100 mSingle mode fiber (SM) 9/125 µm:see SFP module M-FAST SFP-SM/LC and SFP module M-SFP-LX/LCSingle mode fiber (LH) 9/125 µm (long haul transceiver):see SFP module M-FAST SFP-SM+/LCMultimode fiber (MM) 50/125 µm:see SFP module M-FAST SFP-MM/LC and SFP module M-SFP-SX/LCMultimode fiber (MM) 62.5/125 µm:see SFP module M-FAST SFP-MM/LC and SFP module M-SFP-SX/LCNetwork size - cascadibilityLine - / star topology:anyRing structure (HIPER-Ring) quantity switches:50 (reconfiguration time 0.3 sec.)Power requirementsOperating Voltage:100-240 V AC, 50-60 Hz (redundant)Power consumption:35 WPower output in BTU (IT)/h:119Redundancy functions:HIPER-Ring, MRP, MSTP, RSTP - IEEE802.1D-2004, MRP and RSTP gleichzeitig, Link AggregationSoftwareSwitching:Disable Learning (hub functionality), Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, Egress Broadcast Limiter per Port, Flow Control (802.3X), Jumbo Frames, VLAN (802.1Q), GARP VLAN Registration Protocol (GVRP), Double VLAN Tagging (QinQ), Voice VLAN, GARP Multicast Registration Protocol (GMRP), IGMP Snooping/Querier (v1/v2/v3)Redundancy:Advanced Ring Configuration for MRP, HIPER-Ring (Manager), HIPER-Ring (Ring Switch), Fast HIPER-Ring, Link Aggregation with LACP, Media Redundancy Protocol (MRP) (IEC62439-2), Redundant Network Coupling, RSTP 802.1D-2004 (IEC62439-1), MSTP (802.1Q), RSTP Guards, RSTP over MRPManagement:Dual Software Image Support, TFTP, LLDP (802.1AB), LLDP-MED, SSHv1, SSHv2, V.24, HTTP, HTTPS, Traps, SNMP v1/v2/v3, TelnetDiagnostics:Management Address Conflict Detection, Signal Contact, Device Status Indication, LEDs, Syslog, Port Monitoring with Auto-Disable, Link Flap Detection, RMON (1,2,3,9), Port Mirroring 1:1, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check DialogConfiguration:AutoConfiguration Adapter ACA11 Limited Support (RS20/30/40, MS20/30), Automatic Configuration Undo (roll-back), BOOTP/DHCP Client with Auto-Configuration, DHCP Server: per Port, AutoConfiguration Adapter ACA21/22 (USB), HiDiscovery, DHCP Relay with Option 82, Command Line Interface (CLI), CLI Scripting, Full-featured MIB Support, Web-based Management, Context-sensitive HelpSecurity:IP-based Port Security, MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, RADIUS VLAN Assignment, Multi-Client Authentication per Port, MAC Authentication Bypass, Access to Management restricted by VLAN, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner, SNMP Logging, Local User Management, Remote Authentication via RADIUSTime synchronisation:PTPv2 Transparent Clock two-step, PTPv2 Boundary Clock, Buffered Real Time Clock, SNTP Client, SNTP ServerIndustrial Profiles:EtherNet/IP Protocol, PROFINET IO ProtocolMiscellaneous:Manual Cable CrossingAmbient conditionsOperating temperature:0-+50 °CStorage/transport temperature:-20-+85 °CRelative humidity (non-condensing):10-95 %Mechanical constructionDimensions (W x H x D):448 mm x 44 mm x 345 mmWeight:4400 gMounting:19" control cabinetProtection class:IP20Mechanical stabilityIEC 60068-2-6 vibration:3.5 mm, 5–8.4 Hz, 10 cycles, 1 octave/min; 1 g, 8.4–150 Hz, 10 cycles, 1 octave/minIEC 60068-2-27 shock:15 g, 11 ms duration, 18 shocksEMC interference immunityEN 61000-4-2 electrostatic discharge (ESD):4 kV contact discharge, 8 kV air dischargeEN 61000-4-3 electromagnetic field:10 V/m (80-3000 MHz)EN 61000-4-4 fast transients (burst):2 kV power line, 4 kV data lineEN 61000-4-5 surge voltage:power line: 2 kV (line/earth), 1 kV (line/line), 4 kV data lineEN 61000-4-6 Conducted Immunity:10 V (150 kHz-80 MHz)EMC emitted immunityEN 55022:EN 55022 Class AFCC CFR47 Part 15:FCC 47CFR Part 15, Class AApprovalsSafety of industrial control equipment:cUL 508Safety of information technology equipment:cUL 60950-1Scope of delivery and accessoriesAccessories to Order Separately:Fast Ethernet SFP modules, Gigabit Ethernet SFP modules, autoConfiguration Adapter ACA21-USB, terminal cable, Industrial Hivision Network Management softwareScope of delivery:MACH100 device, terminal block for signal contact, 2 brackets with fasteningscrews (pre-assembled), housing feet - stick-on, non-heating appliance cable - Euro model
