Hydropa Ds-117-240/B Pressure Switch

Hydropa

Product Code: Hydropa Ds-117-240/B Pressure Switch
Artikelnummer: Ds-117-240/B
Brand: Hydropa



GET OFFER: info@imtek.com.tr

Description for Hydropa Ds-117-240/B Pressure Switch

TECHNICAL SPECIFICATIONSø 4 mm ø 5 mmSwitching pressure ranges 20-350 bar 20-240 bar 10-150 bar 5-70 barRepeatability deviation less than 1% (depending on the area of ??application)Ambient temperature - 40 ° C to + 90 ° CHydraulic fluid oil, oil-water emulsionSwitching elementelectromechanical switch CEE 24; VDE 0630, T85 UL 1054 / CSA C22.2 No. 55 6 TSD, T90Type of voltage AC voltage / DC voltageDegree of protection DIN 60529 IP 65Power connection cable socket according to EN 175301-803, type A, Pg9 (Pg11 on request)Housing unpainted aluminumPressure connection aluminumSwitching path approx. 0.5 mm - therefore very little wear on the seal and tappet guideConnection plates for valve manifold NG 6 and NG 10 (only for flangeable pressure switches)Piston diameterProfile contact made of pure silver, on request profile contact gold coated on silver palladiumType piston spring-loaded, a mechanical stop prevents the spring from turning on-blockConnection thread G ¼ inside or flange surfaceAdjustment screw cap or knurl adjustmentAdjustment lock fixing coverAny installation positionGeneralHydraulicElectricalOther InformationWeight basic type 0.27 kgP max. (Standard seal) 500 bar 500 bar 400 bar 200 barP max. (SS seal1)) 400 bar 400 bar - bar - barViscosity range 10 to 800 mm² / sLoad changes ?5x1061) Low-friction special sealConductor cross section 0.5 mm² to 1.5 mm²Cable diameter 6 mm to 8 mm for Pg9 / 8 mm to 10 mm for Pg11Sealing outer jacket sealingVoltage 250 V / ACMax. 5 A loadSwitching capacityMax. Inductive load 1 A24 V / DC5 A4 A
