JUMO dTRANS p02 - Pressure Transmitter with Display (404385)

JUMO

Product Code:
Brand: JUMO



GET OFFER: info@imtek.com.tr

Description for JUMO dTRANS p02 - Pressure Transmitter with Display (404385)

FeaturesMedium temperature: -40 to +200 °C (SIP and CIP capable)Local operation (keyboard/LCD) or operation through easy, digital communication (HART protocol) possibleLCD signals occurs if the measuring range is exceeded or not met; signaling also occurs in the event of sensor exceedance and sensor faultsFully welded measuring systemAccessories: pressure separator, valves, setup programMeasuring ranges: -100 to 100 mbar – -1 to 600 bar relative, 0 to 600 mbar – 0 to 25 bar absoluteFor relative pressure, absolute pressure, and levelFor non-aggressive and aggressive gases, vapors, and liquidsHigh linearity: ? 0.1 % from end valueExcellent long-term stability: < 0.1 % per yearExcellent temperature compensationATEX approval available as an optionDepiction through the displayPressure in 13 different units; measured value in %, or scaled with a choice of measuring unitOutput current in mASensor temperature in °C or °FMeasured value error, measured value outside of measuring rangeMinimum pressure and maximum pressure (drag indicator)Pressure and sensor temperature can be displayed simultaneously Settings via the operating keysZero point correctionStart and end of measuring without pressure specification (blind setting) or with pressure specification: simple, time-saving, convenientAttenuationCurrent-generator functionOutput signal in event of malfunction: adjustable to 3.85 mA or 21.5 mALock function for keysReset function for minimum and maximum measured values (drag indicator)Density correction for various measuring mediaMeasuring units for pressure and temperature Customer benefitsProcess reliabilityThe parts coming into contact with the medium made of stainless steel (optionally made of NiMo alloy or Monel with the use of a pressure separator) and a system that is cavity-free reflect the resistance to aggressive media (among other things). The measuring device has a high degree of precision with a deviation from characteristic line of 0.1 % and offers an excellent long-term stability of < 0.1 % per year. The high-temperature version guarantees safe application in SIP and CIP systems. Uncomplicated and time-savingThe measuring device can be operated reliably and easily either on site or set through a more easy-to-use setup program (HART interface).ApplicationsFood and beverage industryPharmaceutical industryChemical and petrochemical industriesWater and wastewater engineeringPaper manufacturingOil and gas industryPower stations
