Kracht KP2/25 S10A Y00 4DL1 Gear Pump

Kracht

Product Code: KP2/25 S10A Y00 4DL1
Brand: Kracht



GET OFFER: info@imtek.com.tr

Description for Kracht KP2/25 S10A Y00 4DL1 Gear Pump

Mounting flange typePipe connection flangeDirection of rotation clockwise or anticlockwiseWeight see dimension sheetsMounting position optionalAmbient temperature ?u min = – 20 °C?u max = 60 °COperating pressure Inlet port pe min = – 0.4 bar (vacuum)pe max = 2 barOperating pressure Short time pe max = 5 barOperating pressure Outlet port pe max = 300 barFluid temperature range ?m max 90 °C for NBR rotary shaft lip type seal?m max 150 °C for FKM rotary shaft lip type sealViscosity ?min = 10 mm2/s?max = 600 mm2/sRecommended filtration filter with filtration quotient?25 ? 75 for … 300 bar?40 ? 75 for … 100 barRecommended viscosity range ? = 30 … 45 mm2/sDischarge flow see chart page 7 and 8Input power see chart page 7 and 8Hydraulic fluids mineral oil acc. to DIN 51524/25engine oil acc. toflame-retardant hydraulic fluids on requestbio-oils of typ „HEES“, can be used up to 70 °C,max. pressure must be reduced minus 20 %(use only on request)
