Meggitt Vibro-Meter TQ401 Proximity Sensor

Meggitt

Product Code: Vibro-Meter TQ401
Brand: Meggitt



GET OFFER: info@imtek.com.tr

Description for Meggitt Vibro-Meter TQ401 Proximity Sensor

8 mV/µm or 2.5 µA/µm (2 mm range), ?40 to 180 °C, Ø5 mm tip, standard-mount.The TQ401 proximity sensor is a high-quality, high-reliability sensor for use with an EA401 extension cable and IQS450 signal conditioner, which provides either a voltage output or a current output.The TQ401 is a standard-mount sensor that is designed and built for long-term use in extreme environments characterised by high temperatures and/or hazardous areas (potentially explosive atmospheres).FeaturesDesigned for the contactless measurement of relative vibration and axial displacement in turbines, compressors, pumps and fans2 mm measurement range (Ø5 mm sensor)?40 to 180 °C operating temperature, IP68 protection rating0.5, 1.0, 1.5, 2.0 or 5.0 m integral coaxial cable.Certified for use in potentially explosive atmospheres PARAMETER VALUE (IMPERIAL | METRIC) Linear measurement range 0.08 in | 2 mm Operating temperature range ?40 to 356 °F | ?40 to 180 °C Sensor (tip) diameter Ø0.2 in | Ø5 mm Mounting options Standard mount Integral cable length 1.6, 3.3, 4.9, 6.6 or 16.4 ft | 0.5, 1.0, 1.5, 2.0 or 5.0 m Protection rating IP68 Hazardous area certifications Ex ia, Ex nA
