Meggitt Vibro-Meter VibroSmart® VSV301 600-034 Monitoring Module

Meggitt

Product Code: Vibro-Meter VibroSmart® VSV301
Brand: Meggitt



GET OFFER: info@imtek.com.tr

Description for Meggitt Vibro-Meter VibroSmart® VSV301 600-034 Monitoring Module

The VibroSmart® VSV301 monitoring module has two independent dynamic vibration channels and one auxiliary channel, that can be configured as either a tachometer or a DC input channel. This processing module is capable of stand-alone vibration monitoring or can be integrated with other VibroSmart modules to create more comprehensive measurement blocks.The VSV301 module performs the data acquisition and all of the signal processing (filtering, analog-to-digital conversion, time and frequency domain processing, and resampling) required to produce processed outputs and extracted data for physical output and data presentation in VibroSight Vision and VibroSight Scope. This includes spectral band extractions, advanced FFT analysis, trending and limit checks (alarm and sensor OK), and run-up / run-down acquisition.Note: The VSV301 monitoring module matches or betters the specifications and performance of  the VSV300 monitoring module, for which it is it is a form, fit and functionally equivalent replacement. The VSV301 also uses the same VSB300 terminal base, making it easy to replace a VSV300 with a VSV301.Features2 dynamic channels and 1 auxiliary channel (tachometer or DC input)Up to 20 processed outputs per module (for the 2 dynamic channels, 1 auxiliary channel and 1 dual-shaft relative channel)Highly configurable module supports simultaneous data acquisition on all channels, with asynchronous/synchronous sampling depending on the processing24-bit data acquisition, high SNR data processing, with a high-resolution FFT up to 1600 lines every 1 sHighly integrated module (with VSB300 terminal base) includes sensor power supplies, buffered outputs, DC outputs, relays and Ethernet communications interfaces PARAMETER VALUE (IMPERIAL | METRIC) Monitoring system (application) Machinery protection, condition monitoring, combustion monitoring VibroSmart system function Machinery protection, condition monitoring, combustion monitoring VibroSmart system component Processing module VibroSmart component function Machinery monitoring VibroSmart module measurement channels 2 dynamic channels and 1 auxiliary channel
