Netter NTK Series Pneumatic Linear Vibrator

Netter

Product Code: NTK Series
Brand: Netter



GET OFFER: info@imtek.com.tr

Description for Netter NTK Series Pneumatic Linear Vibrator

The pneumatic linear vibrators series NTK are especially suitable for conveying and compacting bulk material, due to the completely linear vibration. The linear vibration is produced by a freely oscillating, self-reversing piston. NTK linear vibrators start and stop instantly in any installed position. The noise level is lower than 80 db (A). The frequency can be adjusted continuously by regulating the air supply. The amplitude can be adjusted by throttling the exhaust air. A special feature of the NTK vibrators is the variety of mounting options. It is possible to attach the housing or the piston to a vibrating mass. Additional weights (SM) allow frequencies and the amplitudes to be set.Features-Linear vibration -Nominal frequency from 519 min-1 to 3,800 min-1 -Centrifugal force from 14 N to 4,748 N -Variable additional weights -Frequency and amplitude are separately adjustable -Stainless steel version available -Ex II 2 GD 85°C (T6) available (ATEX)Types: NTK 8, NTK 15, NTK 16, NTK 18, NTK 25, NTK 28, NTK 40, NTK 55, NTK 85, NTK 110
