Nippon P010 NOP Coolant Unit E Series

Nippon

Product Code: P010
Brand: Nippon



GET OFFER: info@imtek.com.tr

Description for Nippon P010 NOP Coolant Unit E Series

Series name E SERIES EP(Specification: TurbulenceTM filter + Plunger pump) E SERIES ET?ES(Specification: TurbulenceTM filter + TrochoidTM pump) Specifications for pump proper Pump model P00850Hz / 60Hz P01050Hz / 60Hz P01450Hz / 60Hz P01650Hz / 60Hz T20850Hz / 60Hz T21650Hz / 60Hz S20850Hz / 60Hz S21650Hz / 60Hz Flow rate (?/min) 12.0 / 14.4 15.0 / 18.0 21.0 / 25.2 24.0 / 28.8 12.0 / 14.4 24.0 / 28.8 12.0 / 14.4 24.0 / 28.8 Compatible fluid Water-soluble coolant fluid Water-soluble coolant fluid / Water-insoluble coolant fluid Maximum allowable viscosity (mm²/s)(Filtring performance) 15 (20µm) 15 (20µm) , 32 (50µm) Liquid temperature range (?) -5 ? 60 Rotational speed (r/min) 1500 / 1800 Maximum pressure (MPa) 7.0 / 7.0 7.0 / 6.0 7.0 / 7.0 3.5 / 3.0(2.2 kW)7.0 / 6.0(3.7 kW) 1.5 / 1.5 2.0 / 2.0 1.5 / 1.5 2.0 / 2.0 Total pump head (m) - Filter type Wire screen filter Filtring performance 20µm 20µm / 50µm Contaminant drain port flow rate (l/min) 30?40(Pressure 0.02MPa) Remarks Install a plate filter of #18 or finer mesh on the suction end of the tank. Painted color of the pump section Flat black (Approximately Munsell N1.0) Approximate weight (kg) 20 16 Relief valve specifications Type External return type Relief pressure setting (MPa) 7.0 / 7.0 7.0 / 6.0 7.0 / 7.0 3.5 / 3.0(2.2 kW)7.0 / 6.0(3.7 kW) 1.5 / 1.5 2.0 / 1.5 1.5 / 1.5 2.0 / 1.5
