Rhomberg SP104 1Ph Current Monitor 200mA, 60mV, 150mV, 5V

Rhomberg

Product Code: SP104
Brand: Rhomberg



GET OFFER: info@imtek.com.tr

Description for Rhomberg SP104 1Ph Current Monitor 200mA, 60mV, 150mV, 5V

11-pin plug-in.Fail-to-safe design.Programmable for overload or underload monitoring.0-200mA AC (RMS)/DC 60mV/150mV (DC Shunt) 0-5V AC (RMS)/DCDirect interface to DC shunt resistors.Internal shunt for direct in-line sensing current up to 200mA (AC/DC)Trip point adjustable on percentage scale (10% to 100%).Adjustable hysteresis (5% to 30%).Adjustable response time on trip (0.1 to 10 seconds).Start-up delay 10 sec fixed.Selectable latching (ie manual or auto reset).Relay ON LED.10A SPDT relay output.Supersedes SP101Requires optional S3-B 11-pin base
