Servomech TMA 15 Mechanical Linear Actuator

Servomech

Product Code: TMA 15
Brand: Servomech



GET OFFER: info@imtek.com.tr

Description for Servomech TMA 15 Mechanical Linear Actuator

Trunnion mouting linear actuatorsTrunnion mounted housing fixed with pins or bronze bushes. High precision worm gearbox, ZI involute profile.Lubrication with synthetic grease (gearbox long life lubricated, screw drive regreasable).TMA Series, acme screw drive:6 standard sizes availableAcme screw from Ø 22 mm to Ø 80 mmLinear speed from 0,1 mm/s to 40 mm/sLoad capacity from 15 kN to 200 kNStandard stroke length up to 1.500 mm, special stroke length also available upon requestPerformances with Duty Cycle Fi = 30 % over 10 min at ambient temperature 25 °CAvailable accessories (*):Stroke length limit device (magnetic or inductive proximity)Incremental or absolute encoder for positioning controlPrepared for IEC standard motors, AC or DC motorsProtective bellowsMore option upon request (*):Push rod in stainless steel AISI 304Lubricants for high or low ambient temperatureLubricants suitable for food industryVITON or silicone special seals
