Skf MKU-U015 Float Switch
Technical Datasheets / Product Documentations
| Brand |  |
| Category | Switch |
| Product Name | Skf MKU-U015 Float Switch |
| Product Code | MKU-U015 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
SKF products, including Skf MKU-U015 Float Switch, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine SKF parts at competitive prices. Even if Skf MKU-U015 Float Switch is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
11203US
Technical data Gear pump unit
Level indicator
Flow rate at 50 Hz . . . . . . . . . . . . . . 0.1; 0.2 or 0.5 l/min at 60 Hz . . . . . . . . . . . . . . 0.12; 0.24 or 0.6 l/min
Function. . . . . . . . . . . . . . . . . . . opens in event of low lubricant
Max. switching voltage . . . . . . . 42 V AC Max. switching current . . . . . . . 0.7 A
(ohmic load) Max. contact rating . . . . . . . . . . 50 VA 2)
in relation to a service viscosity of 140 mm2/s, at a back pressure of p = 5 bars
Operating pressure . . . . . . . . . . . . . 30
+1 2
bars
corresponds to actual value of builtin safety valve
Operating temperature. . . . . . . . . . . +10 to + 40 °C Medium . . . . . . . . . . . . . . . . . . . . . . oil on a petroleum or
synthetic basis compatible with . . . . . . . . . . . . . . . plastics, NBR elastomers,
copper, copper alloys Service viscosity MKU1 units: . . . . . . . . . . . . . . . . 20 750 mm 2/s
MKU2, MKU5 units: . . . . . . . . . . 20 1500 mm 2/s Reservoir capacity . . . . . . . . . . . . . . nominal 1.8, 3 or 6 l
Reservoir material . . . . . . . . . . . . . . plastic or metal Type of enclosure. . . . . . . . . . . . . . . IP 54
Frequency/voltage . . . . . . . . . . . . . . 50/60 Hz, 115 V AC or 50/60 Hz, 230 V AC
Pressure switch Type of contacts . . . . . . . . . . . . closes when pressure builds up
Max. switching voltage . . . . . . . 42 V AC Max. switching current . . . . . . . 2.5 A
(ohmic load) Max. contact rating . . . . . . . . . . 30 VA 2) Switching pressure . . . . . . . . . . 20 bars
1)
please indicate when ordering
Motor with builtin thermostatic switch Mode of operation . . . . . . . . . . . . . . S3, 20 % (1.25 to 25 min)
duty cycle 1) Power consumption approx. . . . . . 50 Hz: 115 W; 60 Hz: 140 W
Speed . . . . . . . . . . . . . . . . . . . . . . . 50 Hz: 2700 rpm;
60 Hz: 3300 rpm
The maximum permissible pump running time amounts to 3 minutes.
That results in a necessary idle time of 15 minutes.
2)
Dimensions in mm
MKU1K(W)210…
1) Ports tapped for solderless tube connection for 8 mm diam. tube
Drawing 1
The 20 % duty cycle is the ratio of the pump running time to the subsequent idle time
Example:
1 minute of pump running time requires at least 5 minutes of idle time.
2) Diameter for power lead 6 ... 8 mm
Take appropriate measures to protect contacts when switching inductive loads.
3
