Sumitomo Fine Cyclo A-Series F1 Type Motion Control
Sumitomo
Product Code: Fine Cyclo A-Series F1 Type
Brand: Sumitomo
GET OFFER: info@imtek.com.tr
Description for Sumitomo Fine Cyclo A-Series F1 Type Motion Control
OverviewCombination of zero backlash gearbox and precision cross roller bearing. Less than 1 arcmin Lost Motion Sizes 45, 65 and 75 provide extremely high support capacity at output shaft Fully sealed Maintenance free for life. Specialized bearing design allows for re-greasing to extend life. Motor adapter provided on request Input Shaft Variants: Keyway Clamp Ring SplineTechnical InfoZero Mechanical Backlash Lost Motion <1 arcmin Number of Sizes 6 Reduction Ratios 29:1 / 59:1 / 89:1 / 119:1 / 179:1 (availability depending on size) Nominal Torque 149 Nm up to 3900 Nm Acceleration Torque 335 Nm up to 7610 Nm Max. Momentary Peak Torque 785 Nm up to 24000 Nm Input Speed up to 6150 rpm Max. Bending Moment 460 Nm up to 14400 Nm Bending Stiffness up to 15600 Nm/arcmin Torsional Stiffness up to 1100 Nm/arcminRecommended Products For Sumitomo
