Wilkerson M26-C2-000 J06 Coalescing Filter

Wilkerson

Product Code: M26-C2-000 J06 Filter
Brand: Wilkerson



GET OFFER: info@imtek.com.tr

Description for Wilkerson M26-C2-000 J06 Coalescing Filter

FeaturesThis coalescing filter includes:Manual Drain0.01 Micron Rated Filter ElementQuick-disconnect Bowl Guard withIntegral Plastic Bowl and Safety LatchDifferential Pressure IndicatorSpecificationsFlow Capacity*1/4"55 SCFM (25.9 dm3/s)3/8"65.5 SCFM (30.9 dm3/s)1/2"79.5 SCFM (37.5 dm3/s)Maximum Supply PressurePlastic Bowl150 PSIG (10.3 bar)Metal Bowl200 PSIG (13.8 bar)Operating TemperaturePlastic Bowl32° to 125°F (0° to 52°C)Metal Bowl32° to 150°F(0° to 65.5°C)Port SizeNPT / BSPP-G1/4, 3/8, 1/2Standard Filtration(micron)(B) 0.5, (C) 0.01, (D) 0.003 mg/m3 **Weight2.4lb. (1.1 kg)* Inlet pressure 150 PSIG (10.3 bar). Pressure drop 3 PSID (0.2 bar).** Filtration temperature of 70°F (21°C) @ 100 PSIG (6.9 bar) with typical compressor lubricating oil and protected by Type C filter."M" Series Coalescing Filters, with Type "B" 0.5 micron elements: All Wilkerson Type "M" Oil Removal (Coalescing) Filters with Type "B" 0.5 micron elements exceed ISO Class 2 for maximum particle size and concentration of solid contaminants, and exceed Class 3 on maximum oil content (mg/m3)."M" Series Coalescing Filters, with Type "C" 0.01 micron elements: All Wilkerson Type "M" Oil Removal (Coalescing) Filters with Type "C" 0.01 micron elements exceed ISO Class 1 for maximum particle size and concentration of solid contaminants, and exceed Class 1 on maximum oil content (mg/m3)."M" Series Adsorption Filters, with Type "D" 0.003 micron activated carbon elements: All Wilkerson Type "M" adsorption filters with Type "D" 0.003 micron activated carbon elements exceed ISO Class 1 on maximum oil content (mg/m3).
