Wilkerson M35 Series Coalescing Filter

Wilkerson

Product Code: M35 Series
Brand: Wilkerson



GET OFFER: info@imtek.com.tr

Description for Wilkerson M35 Series Coalescing Filter

M35-0C-000 M35-0C-S00  M35-0B-F00 M35-0B-FS0M35-0C-F00 M35-0C-FS0 M35-0B-000FeaturesThis coalescing filter includes:Heavy-duty Cast Aluminum Housings to WithstandOperating Pressures Up to 300 PSIG†Differential Pressure Indicator to Eliminate theGuesswork of Element ReplacementUnique Drain Mounting Plate Design Offers TroublefreeMethod for Interchanging and Installing External DrainsHigh-flow Filter Elements: Coalescing, 1 Micron and 0.01 MicronSpecificationsFlow Capacity*1-1/2"710 SCFM (335 dm3/s)2"710 SCFM (335 dm3/s)Maximum Supply PressureWithout DP2300 PSIG (20.7 bar)†With DP2150 PSIG (10.3 bar)Operating Temperature32° to 150°F (0° to 65.5°C)Port SizeNPT / BSPP-G1-1/2, 2Standard Filtration(micron)(B1) 1.0, (C) 0.01, (D) 0.003 mg/m3 **Weight19.3lb. (8.7 kg)* Inlet pressure 150 PSIG (10.3 bar). Pressure drop 3 PSID (0.2 bar).** Filtration temperature of 70°F (21°C) @ 100 PSIG (6.9 bar) with typical compressor lubricating oil and protected by Type C filter.† Without differential pressure indicator -- max. supply pressure is 300 PSIG (20.7 bar)."M" Series Coalescing Filters, with Type "B1" 1.0 micron elements: All Wilkerson Type "M" Oil Removal (Coalescing) Filters with Type "B1" 1.0 micron elements exceed ISO Class 2 for maximum particle size and concentration of solid contaminants, and exceed Class 3 on maximum oil content (mg/m3)."M" Series Coalescing Filters, with Type "C" 0.01 micron elements: All Wilkerson Type "M" Oil Removal (Coalescing) Filters with Type "C" 0.01 micron elements exceed ISO Class 1 for maximum particle size and concentration of solid contaminants, and exceed Class 1 on maximum oil content (mg/m3)."M" Series Adsorption Filters, with Type "D" 0.003 micron activated carbon elements: All Wilkerson Type "M" adsorption filters with Type "D" 0.003 micron activated carbon elements exceed ISO Class 1 on maximum oil content (mg/m3).
