Wilkerson WRA302 Series High Precision Regulator

Wilkerson

Product Code: WRA302 Series
Brand: Wilkerson



GET OFFER: info@imtek.com.tr

Description for Wilkerson WRA302 Series High Precision Regulator

FeaturesControl sensitivity of .250" (.63 cm) water column variation allows use in precision applications.A compensating diaphragm lets the regulator remain unaffected by supply pressure changes.Flow of up to 40 SCFM with 100 PSIG supply allows use in applications with high flow requirements.An aspirator tube compensates downstream pressure droop under flow conditions.A separate Control Chamber isolates the diaphragm from the main flow to eliminate hunting and buzzing.Unit construction lets you service the Regulator without removing it from the line.SpecificationsSupply Pressure250 PSIG, (17.0 bar), (1700 kPa) MaximumFlow Capacity40 SCFM (68 m3/HR) @ 100 PSIG, (7.0 bar),(700 kPa) Supply and 20 PSIG, (1.5 bar),(150 kPa) SetpointExhaust Capacity2.0 SCFM (3.4 m3/HR) where Downstream Pressure is 5 PSIG, (.35 bar), (35 kPa) above 20 PSIG, (1.5 bar), (150 kPa) SetpointSupply Pressure EffectLess than 0.2 PSIG, (.014 bar), (.14 kPa) for 100 PSIG, (7.0 bar), (700 kPa) change in Supply PressureSensitivity.250" (.010 PSIG) (.64 cm) Water ColumnAmbient Temperature-40°F to +200°F, (-40°C to 93°C)
