Woerner KFI-V LEVEL SWITCH

Woerner

Product Code: Woerner KFI-V LEVEL SWITCH
Artikelnummer: KFI-V
Brand: Woerner



GET OFFER: info@imtek.com.tr

Description for Woerner KFI-V LEVEL SWITCH

Level switch KFI-V Application: Function: Technical Data: Technical Data - Reed Contact: Registration of liquid levels in reservoirs. One or two Reed contacts are integrally cast in a sliding tube. A float with a permanent solenoid moves along the sliding tube to match the filling level. When the solenoid approaches the Reed contact the latter is operated without contact. With the type range KFI changeover contacts are used. In the respective switching positions the rising of the float is prevented by means of adjusting rings. The terminal box has two displaced cable entries. Instead of cable unions plug-and socket connections can be screwed in as well (see accessories). Operating pressure max.: 10 bar Ambient temperature max.: 90°C Media temperature max.: 130°C Mounting position: vertically ± 20° Material: Float, sliding tube and flange: 1.4571 Terminal box: cast aluminium GD-AlSi12 Protection type: IP 65 Weight at L1=300: 1,0 kg
