Celem CSP 405A Conduction Cooled Capacitor

Celem

Product Code: CSP 405A
Brand: Celem



GET OFFER: info@imtek.com.tr

Description for Celem CSP 405A Conduction Cooled Capacitor

The CSP 405A offers superior electrical characteristics in the same physical dimensions as the CSP 305A. Please note that the newer CSP 305A/600  has the same physical dimensions as the CSP 405A but is rated for higher power and can provide up to 600kVAr. Standard applications: Induction heating, resonant circuits, medical imaging, heat treatment, plasma applications, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters, etc. Features: Polypropylene Conduction-cooled capacitor High Power Self-Healing capacitor Low ESR Low losses UL94-V0 available upon request. The CSP 405A capacitor complies with RoHS.Specifications TYPE CSP 405A Dimensions (LxWxH) mm 66 x 56 x 30.2 Weight kg 0.6 Capacitance (±10%) ?F 0.1 0.2 0.33 0.66 1 1.33 2.6 5 Sinusoidal Voltage Vrms 1000 800 900 700 500 Peak Voltage Vpeak 1410 1130 1270 990 710 Max. Current Arms 400 600 650 850 950 1000 Max. Power kVAr 400 Freq Range @ Full Power kHz 637-637 318-318 193-434 97-217 100-168 59-216 50-138 51-80 Stray Inductance nH < 5
