EKF SCZ-NVM Mezzanine Side Card for CPU Boards

EKF

Product Code: EKF SCZ-NVM Mezzanine Side Card for CPU Boards
Artikelnummer: SCZ-NVM
Brand: EKF



GET OFFER: info@imtek.com.tr

Description for EKF SCZ-NVM Mezzanine Side Card for CPU Boards

GeneralMixed function mezzanine side card for EKF CompactPCI® Serial CPU boardsBased on new mezzanine connectors HSE1/HSE2 (8 x PCIe, DP, USB3)Suitable e.g. for use with CPU cards SC4-CONCERTO, SC5-FESTIVALProvides additional front panel I/O, and dual M.2 NVMe SSD8HP assembly together with CPU card12HP assembly in total with CPU card and C32-FIO mezzanine  Front Panel I/OVariety of front panel I/O options:USB 3.1 Gen1 xHCI SuperSpeed F/P Type-A connectorDisplayPort F/P connector (standard type, latched), 3rd graphics output2 x RS-232 male D-Sub 9-pin (COM port) F/P connectorsOption C32-FIO legacy front panel I/O (2 x RS-232, 1 x USB2 Type-A)Integrated 8HP front panel for CPU card and SCZ-NVM (12HP when C32-FIO third floor mezzanine is installed in addition)  On-Board Mass Storage Options1 x M.2 connector (formerly known as NGFF), M-key, suitable for NVMe (PCIe Gen3 x4) SSD modules, up to 22110 size1 x M.2 connector, M-key, suitable for standard NVMe (PCIe Gen3 x2) SSD and special function modules e.g. Intel® Optane™, or EKF M01-NVSRAM, up to 22110 size  UARTDiodes/Pericom PI7C9X7954 PCI Express® bridge to quad port UART (Universal Asynchronous Receiver Transmitter), 16C550-type compatible, up to 15MbpsTwo ports with RS-232 transceivers MAX3243E, TIA/EIA-232-F, up to 250kbps, for front panel I/O (D-Sub connectors 9-pin male, COM port pin assignment)Two UART ports for use on C32-FIO mezzanine module (option), TTL level signals  ApplicationsLocal expansion (side card) for EKF CPU boardsNVMe SSD based mass storage solution, 2 x M.2 connectors for PCIe based modulesClassic COM port front I/O (RS-232), expandable to 4 ports3rd DisplayPort receptacle (video output) for 4k capable multi-monitor applicationsUSB 3.0 based port for communication or removable storage  Regulation & EnvironmentalDesigned & manufactured in GermanyISO 9001 certified quality managementCustom specific development on requestLong term availabilityCoating, sealing, underfilling on requestRoHS compliant 2002/95/ECOperating temperature 0°C to +70°C (commercial temperature range)Operating temperature -40°C to +85°C (industrial temperature range) on requestStorage temperature: -40°C to +85°C, max. gradient 5°C/minHumidity 5% ... 95% RH non condensingAltitude -300m ... +3000mShock 15g 0.33ms, 6g 6msVibration 1g 5-2000HzEC Regulations EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1)MTBF 59.6 years
