Nom du Produit: Aoip 944 True Surface Temperature Measurement System
Marque: Aoip
Code Produit: 944
Mots-clés: Aoip
Aoip 944 Surface Measurement
Aoip True Surface System
944 True
Aoip 944 True Surface System
944 True Surface Measurement
Aoip True Surface Measurement System
Surface Temperature System
944 True Surface Temperature System
Aoip 944 Temperature
Aoip True Surface Temperature System
Aoip True Surface Temperature Measurement System
944 True Surface Temperature Measurement
944 Temperature Measurement System
944 True Temperature
True Surface Measurement
Aoip True
944 True Surface Measurement System
944 Surface Temperature System
Aoip 944 True Temperature
True Surface Temperature Measurement System
Êtes-vous intéressé par le produit Aoip 944 True Surface Temperature Measurement System du fabricant Aoip avec le code 944? Contactez-nous maintenant et obtenez une offre. Imtek Engineering, le fournisseur d\'équipements industriels le plus rapide et le plus fiable au monde, vous offrira la meilleure offre!
Obtenez une offre par e-mail: info@im-tek.com
Obtenez une offre pour Aoip 944 True Surface Temperature Measurement System de notre équipe de support en direct maintenant!
The fundamental problem with surface temperature measurement is that it is subject to large stem conduction errors, also because heat conducted from the surface of the hot plate causes a localized cold spot to be created. It means that the temperature indicated by the hot plate is not necessarily the temperature at the point of measurement.An ideal system would not disturb the heat flux from the hot plate, which is exactly what 944 system does.Key features:Indicated true surface temperatureTemperature operating range: 30°C to 350°CResolution of 0.1°CPrinciple of operationA fine wire type N thermocouple is used as the surface temperature sensor. A second junction of 2 to 3 mm along the thermocouple senses the temperature difference due to heat flux along the sensor.A heater heats the thermocouple stem until the temperature gradient is zero, thus creating a measurement without stem conduction, or disturbance of the hot plate’s surface.944 system can be used with the surface sensor calibrator 983.Temperature range30°C to +350°CStability±1°CAccuracy±2°C with traceable certification±5°C without certificationProbe assemblyDiameter: 7.5 mmLength: 150 mmLead length: 850 mmGeneral specificationsSize90 x 153 x 265 mmWeight4 kgDisplayResolution: 0.1°C or 0.1°FPower supply100 / 120 V (50/60 Hz) or 200 / 240 V (50/60 Hz)
